LP5912-3.3DRVT
RoHS
RoHS compliant
RoHS compliantPackage 6-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP5912 Tape & Reel (TR) Surface Mount Over Temperature Reverse Polarity Short Circuit voltage regulator linear 950mV 800mum 500mA -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.3376
≥1 USD $1.3376
≥10 USD $1.20384
≥100 USD $1.135552
≥500 USD $0.967384
Inventory: 1145
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-WDFN Exposed Pad
Number of Pins 6
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Position DUAL
Terminal Form NO LEAD
Number of Functions 1
Base Part Number LP5912
Current - Supply (Max) 600μA
Number of Outputs 1
Voltage - Input (Max) 6.5V
Output Voltage 3.3V
Output Type Fixed
Output Configuration Positive
Current - Output 500mA
Quiescent Current 30μA
Control Features Enable, Power Good, Soft Start
Output Voltage 1 3.3V
Input Voltage (Min) 3.8V
Number of Regulators 1
Protection Features Over Temperature, Reverse Polarity, Short Circuit
Current - Quiescent (Iq) 55μA
Voltage Dropout (Max) 0.18V @ 500mA
PSRR 80dB ~ 40db (100Hz ~ 100kHz)
Dropout Voltage 950mV
Dropout Voltage1-Nom 0.15V
Dimensions
Height 800μm
Length 2mm
Width 2mm
Thickness 750μm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
