LP4951CMX
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Contains Lead Positive GULL WING voltage regulator linear -40C~125C 100mA 4.9mm 380mV
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.40705
≥100 USD $4.2693
≥500 USD $4.13155
≥1000 USD $3.9938
Inventory: 1694
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 235
Number of Functions 1
Base Part Number LP4951
Current - Supply (Max) 19mA
Number of Outputs 1
Voltage - Input (Max) 30V
Output Voltage 29V
Output Type Adjustable
Max Output Current 100mA
Output Configuration Positive
Quiescent Current 15mA
Control Features Enable
Accuracy 0.5 %
Output Voltage 1 5V
Voltage - Output (Min/Fixed) 1.235V
Number of Regulators 1
Min Input Voltage 2.43V
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 170μA
Voltage Dropout (Max) 0.6V @ 100mA
Reference Voltage 1.285V
Dropout Voltage 380mV
Dropout Voltage1-Nom 0.38V
Voltage Tolerance-Max 4%
Min Current Limit 200mA
Input Voltage Absolute-Max 30V
Output Voltage Accuracy 0.5 %
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
