LP3985ITL-5.0/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 5-WFBGA, DSBGA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP3985 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 60mV 675mum 150mA 244mW
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8272
≥1 USD $0.8272
≥10 USD $0.72424
≥100 USD $0.680416
≥500 USD $0.555456
Inventory: 1154
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 5-WFBGA, DSBGA
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Subcategory Other Regulators
Packing Method TR
Max Power Dissipation 244mW
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number LP3985
Pin Count 5
Number of Outputs 1
Voltage - Input (Max) 6V
Output Voltage 5V
Output Type Fixed
Max Output Current 150mA
Output Configuration Positive
Power Dissipation 244mW
Quiescent Current 250μA
Control Features Enable
Accuracy 2 %
Output Voltage 1 5V
Number of Regulators 1
Min Input Voltage 2.5V
Protection Features Over Current, Over Temperature, Short Circuit
Current - Quiescent (Iq) 150μA
Voltage Dropout (Max) 0.1V @ 150mA
PSRR 50dB ~ 40dB (1kHz ~ 10kHz)
Dropout Voltage 60mV
Dropout Voltage1-Nom 0.06V
Voltage Tolerance-Max 3%
Output Voltage Accuracy 2 %
Min Current Limit 300mA
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 675μm
Width 1.2mm
Length 1.5mm
Height 675μm
