LP3985IM5X-4.7
RoHS
/
Package SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP3985 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 60mV 2.9mm 150mA 250mW
PDF
/
Buying Options
Total Price: USD $0.12
Unit Price: USD $0.1232
≥1 USD $0.1232
Inventory: 1154
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Other Regulators
Packing Method TAPE AND REEL
Max Power Dissipation 250mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number LP3985
Pin Count 5
Number of Outputs 1
Voltage - Input (Max) 6V
Output Voltage 4.7V
Output Type Fixed
Max Output Current 150mA
Output Configuration Positive
Power Dissipation 250mW
Quiescent Current 250μA
Control Features Enable
Accuracy 2 %
Output Voltage 1 4.7V
Number of Regulators 1
Min Input Voltage 2.5V
Protection Features Over Current, Over Temperature, Short Circuit
Current - Quiescent (Iq) 150μA
Voltage Dropout (Max) 0.1V @ 150mA
PSRR 50dB ~ 40dB (1kHz ~ 10kHz)
Dropout Voltage 60mV
Dropout Voltage1-Nom 0.06V
Voltage Tolerance-Max 3%
Min Current Limit 300mA
Output Voltage Accuracy 2 %
Dimensions
Length 2.9mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
