LP38852SX-ADJ
RoHS
/
Package TO-263-8, D2Pak (7 Leads + Tab), TO-263CA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Contains Lead Positive GULL WING voltage regulator linear -40C~125C 1.5A 8.64mm 130mV
PDF
/
Buying Options
Total Price: USD $4.15
Unit Price: USD $4.1477
≥1 USD $4.1477
≥10 USD $3.40385
≥100 USD $3.29745
≥500 USD $3.19105
≥1000 USD $3.08465
Inventory: 503
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 8.64mm
Technical
Dropout Voltage1-Nom 0.13V
Dropout Voltage 130mV
PSRR 80dB ~ 65dB (120Hz ~ 1kHz)
Voltage Dropout (Max) 0.18V @ 1.5A
Current - Quiescent (Iq) 300μA
Protection Features Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Min Input Voltage 930mV
Number of Regulators 1
Voltage - Output (Min/Fixed) 0.8V
Accuracy 1.5 %
Control Features Enable, Soft Start
Quiescent Current 8.5mA
Output Configuration Positive
Max Output Current 1.5A
Output Type Adjustable
Output Voltage 1.8V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Current - Supply (Max) 9mA
Pin Count 4
Base Part Number LP38852
Number of Functions 1
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position SINGLE
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 7
Package / Case TO-263-8, D2Pak (7 Leads + Tab), TO-263CA
Mounting Type Surface Mount
Mount Surface Mount
