LP38843S-0.8/NOPB
RoHS
RoHS compliant
RoHS compliantPackage TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP38843 Tube Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 210mV 4.8mm 3A -40C~125C
PDF
/
Buying Options
Total Price: USD $1.94
Unit Price: USD $1.936
≥1 USD $1.936
Inventory: 1080
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e3
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Regulators
Packing Method RAIL
Technology CMOS
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Base Part Number LP38843
Pin Count 4
Current - Supply (Max) 40mA
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Voltage 800mV
Output Type Fixed
Max Output Current 3A
Output Configuration Positive
Quiescent Current 35mA
Control Features Enable
Accuracy 1.5 %
Output Voltage 1 0.8V
Voltage - Output (Min/Fixed) 0.8V
Number of Regulators 1
Min Input Voltage 1.01V
Protection Features Over Current, Over Temperature, Short Circuit
Current - Quiescent (Iq) 30μA
Voltage Dropout (Max) 0.5V @ 3A
PSRR 80dB ~ 65dB (120Hz ~ 1kHz)
Dropout Voltage 210mV
Dropout Voltage1-Nom 0.21V
Voltage Tolerance-Max 3%
Input Voltage Absolute-Max 6V
Output Voltage Accuracy 1.5 %
Dimensions
Height Seated (Max) 4.8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
