LP38692MP-3.3/NOPB
RoHS
RoHS compliant
RoHS compliantPackage TO-261-5, TO-261AB
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP38692 Tape & Reel (TR) Surface Mount Over Temperature voltage regulator linear 650mV 1.8mm 1A -40C~125C
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.21198
≥1 USD $1.21198
≥10 USD $1.14338
≥100 USD $1.07866
≥500 USD $1.0176
≥1000 USD $0.96
≥3000 USD $0.90566
Inventory: 7150
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-261-5, TO-261AB
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Regulators
Packing Method TR
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number LP38692
Pin Count 5
Number of Outputs 1
Voltage - Input (Max) 10V
Output Voltage 3.3V
Output Type Fixed
Max Output Current 1A
Max Supply Voltage 10V
Min Supply Voltage 2.7V
Output Configuration Positive
Quiescent Current 100μA
Accuracy 2.5 %
Output Voltage 1 3.3V
Number of Regulators 1
Min Input Voltage 2.7V
Protection Features Over Temperature
Current - Quiescent (Iq) 55μA
Voltage Dropout (Max) 1V @ 1A
PSRR 55dB (120Hz)
Dropout Voltage 650mV
Dropout Voltage1-Nom 0.45V
Voltage Tolerance-Max 5%
Nominal Output Voltage 3.3V
Output Voltage Accuracy 2.5 %
Dimensions
Height 1.8mm
Length 6.5mm
Width 3.56mm
Thickness 1.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
