LP3856ES-2.5
RoHS
/
Package TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP3856 Tube Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 390mV 4.8mm 3A -40C~125C
PDF
/
Buying Options
Total Price: USD $4.79
Unit Price: USD $4.79085
≥1 USD $4.79085
≥10 USD $3.9311
≥100 USD $3.8076
≥500 USD $3.68505
≥1000 USD $3.5625
Inventory: 1486
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 8.64mm
Height Seated (Max) 4.8mm
Technical
Voltage Tolerance-Max 3%
Dropout Voltage1-Nom 0.39V
Dropout Voltage 390mV
PSRR 73dB ~ 57dB (120Hz)
Voltage Dropout (Max) 0.6V @ 3A
Current - Quiescent (Iq) 4mA
Protection Features Over Current, Over Temperature, Short Circuit
Min Input Voltage 2.5V
Number of Regulators 1
Output Voltage 1 2.5V
Accuracy 1.5 %
Control Features Enable
Quiescent Current 4mA
Output Configuration Positive
Max Output Current 3A
Output Type Fixed
Output Voltage 2.5V
Voltage - Input (Max) 7V
Number of Outputs 1
Current - Supply (Max) 10mA
Pin Count 4
Base Part Number LP3856
Number of Functions 1
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position SINGLE
Technology CMOS
Packing Method RAIL
Subcategory Other Regulators
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Package / Case TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Mounting Type Surface Mount
Mount Surface Mount
