LP2992AILD-3.3
RoHS
/
Package 6-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Contains Lead Positive BIPOLAR Linear Voltage Regulator IC -40C~125C 250mA 3.29mm 450mV
PDF
/
Buying Options
Total Price: USD $4.9
Unit Price: USD $4.9001
≥1 USD $4.9001
≥10 USD $4.0204
≥100 USD $3.895
≥500 USD $3.7696
≥1000 USD $3.6442
Inventory: 20563
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-WDFN Exposed Pad
Number of Pins 6
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position DUAL
Peak Reflow Temperature (Cel) 235
Number of Functions 1
Terminal Pitch 0.95mm
Base Part Number LP2992
Pin Count 6
Current - Supply (Max) 4mA
Number of Outputs 1
Voltage - Input (Max) 16V
Output Voltage 3.3V
Output Type Fixed
Max Output Current 250mA
Output Configuration Positive
Quiescent Current 65μA
Control Features Enable
Accuracy 3.5 %
Output Voltage 1 3.3V
Number of Regulators 1
Min Input Voltage 2.2V
Protection Features Over Current, Over Temperature, Short Circuit
Current - Quiescent (Iq) 95μA
Voltage Dropout (Max) 0.85V @ 250mA
PSRR 45dB (1kHz)
Dropout Voltage 450mV
Dropout Voltage1-Nom 0.45V
Voltage Tolerance-Max 4.5%
Output Voltage Accuracy 3.5 %
Dimensions
Height Seated (Max) 0.8mm
Length 3.29mm
Width 2.92mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
