LP2988IMX-5.0
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP2988 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 180mV 4.9mm 200mA -40C~125C
PDF
/
Buying Options
Total Price: USD $11.71
Unit Price: USD $11.7059
≥1 USD $11.7059
≥10 USD $9.60545
≥100 USD $9.30525
≥500 USD $9.00505
≥1000 USD $8.70485
Inventory: 1668
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Min Current Limit 250mA
Dropout Voltage1-Nom 0.18V
Dropout Voltage 180mV
PSRR 65dB (1kHz)
Voltage Dropout (Max) 0.35V @ 200mA
Current - Quiescent (Iq) 120μA
Protection Features Over Current, Over Temperature, Short Circuit
Min Input Voltage 2.1V
Number of Regulators 1
Output Voltage 1 5V
Accuracy 1.6 %
Control Features Enable
Quiescent Current 100μA
Output Configuration Positive
Max Output Current 200mA
Output Type Fixed
Output Voltage 5V
Voltage - Input (Max) 16V
Number of Outputs 1
Current - Supply (Max) 3.7mA
Pin Count 8
Base Part Number LP2988
Number of Functions 1
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
