LP2988AIMM-3.0
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP2988 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 180mV 3mm 200mA -40C~125C
PDF
/
Buying Options
Total Price: USD $1.59
Unit Price: USD $1.59315
≥1 USD $1.59315
≥10 USD $1.3072
≥100 USD $1.26635
≥500 USD $1.2255
≥1000 USD $1.18465
Inventory: 1135
Minimum: 1
-
+
Technical Details
Technical
Voltage Dropout (Max) 0.35V @ 200mA
PSRR 65dB (1kHz)
Dropout Voltage 180mV
Dropout Voltage1-Nom 0.18V
Min Current Limit 250mA
Output Voltage Accuracy 0.8 %
Current - Quiescent (Iq) 120μA
Protection Features Over Current, Over Temperature, Short Circuit
Min Input Voltage 2.1V
Number of Regulators 1
Output Voltage 1 3V
Accuracy 0.8 %
Control Features Enable
Quiescent Current 100μA
Output Configuration Positive
Max Output Current 200mA
Output Type Fixed
Output Voltage 3V
Voltage - Input (Max) 16V
Number of Outputs 1
Current - Supply (Max) 3.7mA
Pin Count 8
Base Part Number LP2988
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Dimensions
Length 3mm
Width 3mm
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
