LP2985A-28DBVT
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP2985 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 280mV 1.45mm 150mA -40C~125C
PDF
/
Buying Options
Total Price: USD $1.56
Unit Price: USD $1.5576
≥1 USD $1.5576
≥10 USD $1.39656
≥100 USD $1.317536
≥500 USD $1.122616
Inventory: 1278
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Surface Mount YES
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Packing Method TR
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number LP2985
Pin Count 5
Current - Supply (Max) 2.5mA
Number of Outputs 1
Output Voltage 2.8V
Output Type Fixed
Max Output Current 150mA
Voltage 2.8V
Max Supply Voltage 16V
Min Supply Voltage 2.2V
Output Configuration Positive
Quiescent Current 850μA
Control Features Enable
Accuracy 1 %
Max Output Voltage 2.8V
Output Voltage 1 2.8V
Number of Regulators 1
Min Input Voltage 2.2V
Protection Features Over Current, Over Temperature, Short Circuit
Current - Quiescent (Iq) 95μA
Voltage Dropout (Max) 0.58V @ 150mA
PSRR 45dB (1kHz)
Dropout Voltage 280mV
Dropout Voltage1-Nom 0.28V
Min Output Voltage 2.8V
Nominal Output Voltage 2.8V
Input Bias Current 850μA
Output Voltage Accuracy 1 %
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
