LP2983AIM5-1.0/NOPB
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP2983 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 1.2V 1.45mm 150mA -40C~125C
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 184
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.2mm
Width 1.6mm
Length 2.9mm
Height 1.45mm
Technical
Output Voltage Accuracy 1 %
Dropout Voltage1-Nom 1V
Dropout Voltage 1.2V
PSRR 65dB (1kHz)
Current - Quiescent (Iq) 95μA
Protection Features Over Current, Over Temperature, Short Circuit
Min Input Voltage 2.2V
Number of Regulators 1
Output Voltage 1 1V
Accuracy 1 %
Control Features Enable
Quiescent Current 65μA
Output Configuration Positive
Max Output Current 150mA
Output Type Fixed
Output Voltage 1V
Voltage - Input (Max) 16V
Number of Outputs 1
Current - Supply (Max) 2mA
Pin Count 5
Base Part Number LP2983
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TR
Subcategory Other Regulators
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
