LP2981IM5-4.7
RoHS
/
Package SOT-23-5
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Contains Lead GULL WING Not Qualified BIPOLAR voltage regulator linear 125C 0.1A 2.92mm 7mV
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2112
≥1 USD $0.2112
Inventory: 20556
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Width 1.6mm
Length 2.92mm
Height Seated (Max) 1.22mm
Technical
Operating Temperature TJ-Min -40°C
Line Regulation-Max (%/V) 0.0155%
Adjustability FIXED
Input Voltage Absolute-Max 16V
Operating Temperature TJ-Max 125°C
Output Current1-Max 0.1A
Voltage Tolerance-Max 3.5%
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Dropout Voltage1-Nom 0.2V
Dropout Voltage 7mV
Input Voltage (Max) 16V
Input Voltage (Min) 5.7V
Output Voltage 1 4.7V
Voltage - Output 4.7V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PDSO-G5
Pin Count 5
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.95mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Other Regulators
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn85Pb15)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1
Pbfree Code no
JESD-609 Code e0
Packaging Cut Tape
Physical
Surface Mount YES
Package / Case SOT-23-5
