LP2980IM5X-3.0
RoHS
/
Package SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Not For New Designs Contains Lead Positive GULL WING Linear Voltage Regulator IC -40C~125C 50mA 2.92mm 120mV
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.6916
≥1 USD $0.6916
≥10 USD $0.5681
≥100 USD $0.55005
≥500 USD $0.532
≥1000 USD $0.5149
Inventory: 9794
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Length 2.92mm
Technical
Output Voltage Accuracy 1.5 %
Min Current Limit 100mA
Dropout Voltage1-Nom 0.12V
Dropout Voltage 120mV
PSRR 63dB (1kHz)
Voltage Dropout (Max) 0.22V @ 50mA
Current - Quiescent (Iq) 95μA
Protection Features Over Current, Over Temperature, Short Circuit
Min Input Voltage 2.1V
Voltage - Output (Min/Fixed) 3V
Output Voltage 1 3V
Accuracy 1.5 %
Control Features Enable
Quiescent Current 65μA
Output Configuration Positive
Max Output Current 50mA
Output Type Fixed
Output Voltage 3V
Voltage - Input (Max) 16V
Number of Outputs 1
Current - Supply (Max) 1.2mA
Pin Count 5
Base Part Number LP2980
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
