LP2966IMM-1833
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP2966 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 135mV 860mum 150mA -40C~125C
PDF
/
Buying Options
Total Price: USD $1.4
Unit Price: USD $1.4003
≥1 USD $1.4003
≥10 USD $1.1495
≥100 USD $1.1134
≥500 USD $1.0773
≥1000 USD $1.0412
Inventory: 1130
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height 860μm
Technical
Output Voltage 2 3.3V
Current - Output 2 150mA
Output Voltage Accuracy 1.5 %
Input Voltage Absolute-Max 7.5V
Voltage Tolerance-Max 3.5%
Dropout Voltage1-Nom 0.135V
Nominal Input Voltage 1.8V
Dropout Voltage 135mV
Current - Output 1 150mA
PSRR 60dB ~ 40dB (120Hz)
Voltage Dropout (Max) 0.27V @ 150mA
Current - Quiescent (Iq) 300μA
Protection Features Over Current, Over Temperature, Short Circuit
Min Input Voltage 2.7V
Voltage - Output (Min/Fixed) 1.8V 3.3V
Voltage - Output 2 1.8V
Output Voltage 1 1.8V
Accuracy 1.5 %
Control Features Enable
Quiescent Current 340μA
Output Configuration Positive
Voltage - Output 1 2.5V
Max Output Current 150mA
Output Type Fixed
Output Voltage 3.3V
Voltage - Input (Max) 7V
Number of Outputs 2
Current - Supply (Max) 600μA
Pin Count 8
Base Part Number LP2966
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
