LP2960IM-3.3/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Contains Lead Positive GULL WING Linear Voltage Regulator IC -40C~125C 500mA 9.9mm 470mV
PDF
/
Buying Options
Total Price: USD $1.58
Unit Price: USD $1.58365
≥1 USD $1.58365
≥10 USD $1.2996
≥100 USD $1.25875
≥500 USD $1.2179
≥1000 USD $1.178
Inventory: 2800
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e3
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Regulators
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number LP2960
Pin Count 16
Current - Supply (Max) 40mA
Number of Outputs 1
Voltage - Input (Max) 30V
Output Voltage 3.3V
Output Type Fixed
Max Output Current 500mA
Output Configuration Positive
Quiescent Current 450μA
Control Features Enable
Output Voltage 1 3.3V
Number of Regulators 1
Min Input Voltage -20V
Protection Features Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq) 600μA
Voltage Dropout (Max) 0.8V @ 500mA
Reference Voltage 1.26V
Dropout Voltage 470mV
Dropout Voltage1-Nom 0.8V
Voltage Tolerance-Max 2.4%
Input Voltage Absolute-Max 30V
Load Regulation-Max(%) 0.4%
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
