LM79M05CT/NOPB
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LM79M0 Tube Through Hole Over Temperature Short Circuit voltage regulator linear 1.1V 2.54mm 1mA 0C~125C
PDF
/
Inventory: 8748
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Technical
Operating Temperature 0°C~125°C
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Regulators
Packing Method RAIL
Technology BIPOLAR
Terminal Position SINGLE
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 2.54mm
Current Rating 500mA
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number LM79M0
Pin Count 3
JESD-30 Code R-PSFM-T3
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) -25V
Output Voltage -5V
Output Type Fixed
Output Configuration Negative
Quiescent Current 2mA
Output Voltage 1 5V
Number of Regulators 1
Min Input Voltage -10V
Protection Features Over Temperature, Short Circuit
Current - Quiescent (Iq) 1mA
Voltage Dropout (Max) 1.1V @ 500mA
PSRR 66dB (120Hz)
Dropout Voltage 1.1V
Dropout Voltage1-Nom 1.1V
Voltage Tolerance-Max 5%
Output Current1-Max 0.5A
Input Voltage Absolute-Max 25V
Output Voltage Accuracy 4 %
Compliance
RoHS Status ROHS3 Compliant
