LM79L05ACTLX
RoHS
/
Package 6-WFBGA, DSBGA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LM79L05 Tape & Reel (TR) Surface Mount Over Temperature Short Circuit voltage regulator linear 7V 0.5mm 100mA 0C~70C
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.27645
≥1 USD $0.27645
≥10 USD $0.22705
≥100 USD $0.2204
≥500 USD $0.2128
≥1000 USD $0.20615
Inventory: 1177
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
PSRR 50dB (120Hz)
Current - Quiescent (Iq) 6mA
Protection Features Over Temperature, Short Circuit
Number of Regulators 1
Input Voltage (Min) 7V
Output Voltage 1 5V
Current - Output 100mA
Output Configuration Negative
Output Type Fixed
Output Voltage -5V
Voltage - Input (Max) -35V
Qualification Status Not Qualified
Pin Count 6
Base Part Number LM79L05
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology BIPOLAR
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 6
Package / Case 6-WFBGA, DSBGA
Mounting Type Surface Mount
Mount Surface Mount
