LM78L05ITP/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 8-UFBGA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LM78L05 Tape & Reel (TR) Surface Mount Over Temperature Short Circuit voltage regulator linear 1.6V 575mum 100mA 750mW
PDF
/
Buying Options
Total Price: USD $0.88
Unit Price: USD $0.88
≥1 USD $0.88
≥10 USD $0.78936
≥100 USD $0.749056
≥500 USD $0.615296
Inventory: 1035
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-UFBGA
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Subcategory Other Regulators
Packing Method TR
Max Power Dissipation 750mW
Technology BIPOLAR
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.5mm
Base Part Number LM78L05
Pin Count 8
Number of Outputs 1
Voltage - Input (Max) 35V
Output Voltage 5V
Output Type Fixed
Max Output Current 100mA
Output Configuration Positive
Power Dissipation 750mW
Quiescent Current 5mA
Accuracy 5 %
Output Voltage 1 5V
Number of Regulators 1
Min Input Voltage 6.7V
Protection Features Over Temperature, Short Circuit
Current - Quiescent (Iq) 3mA
PSRR 62dB (120Hz)
Dropout Voltage 1.6V
Dropout Voltage1-Nom 1.6V
Voltage Tolerance-Max 5%
Output Voltage Accuracy 5 %
Dimensions
Height 575μm
Length 0m
Width 0m
Thickness 370μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
