LM3490IM5-3.3
RoHS
/
Package SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LM3490 Tape & Reel (TR) Surface Mount Short Circuit voltage regulator linear 900mV 2.92mm 100mA 300mW
PDF
/
Buying Options
Total Price: USD $4.86
Unit Price: USD $4.857768
≥1 USD $4.857768
≥10 USD $4.582798
≥100 USD $4.323397
≥500 USD $4.078677
≥1000 USD $3.847804
Inventory: 938
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Other Regulators
Packing Method TAPE AND REEL
Max Power Dissipation 300mW
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LM3490
Pin Count 5
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) 30V
Output Voltage 3.3V
Output Type Fixed
Max Output Current 100mA
Output Configuration Positive
Power Dissipation 300mW
Quiescent Current 400μA
Control Features Enable
Accuracy 5 %
Output Voltage 1 3.3V
Input Voltage (Min) 4.8V
Number of Regulators 1
Protection Features Short Circuit
Current - Quiescent (Iq) 4mA
Voltage Dropout (Max) 1.2V @ 100mA
Dropout Voltage 900mV
Dropout Voltage1-Nom 0.9V
Voltage Tolerance-Max 5%
Output Voltage Accuracy 5 %
Dimensions
Length 2.92mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
