LM2941CSX/NOPB

Texas Instruments
RoHS
RoHS RoHS compliant
Package TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description LM2941 Tape & Reel (TR) Surface Mount Over Temperature Reverse Polarity Short Circuit voltage regulator linear 500mV 4.83mm 1A 0C~125C
PDF
/
Buying Options
Total Price: USD $2.08
Unit Price: USD $2.0768
≥1 USD $2.0768
≥10 USD $1.8656
≥100 USD $1.76
≥500 USD $1.499344
≥1000 USD $1.407859
Inventory: 1408
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Thickness 4.58mm
Width 8.42mm
Length 10.16mm
Height 4.83mm

Technical

Load Regulation-Max(%) 0.78%
Dropout Voltage1-Nom 0.5V
Dropout Voltage 500mV
Reference Voltage 1.313V
Voltage Dropout (Max) 1V @ 1A
Current - Quiescent (Iq) 10mA
Protection Features Over Temperature, Reverse Polarity, Short Circuit
Min Input Voltage -15V
Number of Regulators 1
Voltage - Output (Min/Fixed) 5V
Control Features Enable
Quiescent Current 15mA
Output Configuration Positive
Max Output Current 1A
Output Type Adjustable
Output Voltage 20V
Voltage - Input (Max) 26V
Number of Outputs 1
Current - Supply (Max) 15mA
Pin Count 4
Base Part Number LM2941
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position SINGLE
Technology BIPOLAR
Packing Method TR
Subcategory Other Regulators
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 0°C~125°C

Physical

Number of Pins 5
Package / Case TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
