LM2940T-5.0
RoHS
/
Package TO-220-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LM2940 Tube Through Hole Over Current Over Temperature Reverse Polarity Short Circuit voltage regulator linear 500mV 4.7mm 1A -40C~125C
PDF
/
Buying Options
Total Price: USD $1.88
Unit Price: USD $1.88005
≥1 USD $1.88005
≥10 USD $1.5428
≥100 USD $1.49435
≥500 USD $1.4459
≥1000 USD $1.39745
≥3000 USD $1.25305
Inventory: 22009
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 4 days ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e0
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Other Regulators
Technology BIPOLAR
Terminal Position SINGLE
Number of Functions 1
Terminal Pitch 2.54mm
Base Part Number LM2940
Number of Outputs 1
Voltage - Input (Max) 26V
Output Voltage 5V
Output Type Fixed
Max Output Current 1A
Output Configuration Positive
Quiescent Current 15mA
Output Voltage 1 5V
Number of Regulators 1
Min Input Voltage 6.25V
Protection Features Over Current, Over Temperature, Reverse Polarity, Short Circuit
Current - Quiescent (Iq) 10mA
Voltage Dropout (Max) 1V @ 1A
PSRR 64dB (120Hz)
Dropout Voltage 500mV
Dropout Voltage1-Nom 0.5V
Voltage Tolerance-Max 5%
Nominal Output Voltage 5V
Dimensions
Height 4.7mm
Length 14.986mm
Width 10.16mm
Thickness 4.572mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
