LM2937IMPX-3.3
RoHS
/
Package TO-261-4, TO-261AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LM2937 Tape & Reel (TR) Surface Mount Over Temperature Reverse Polarity Short Circuit voltage regulator linear 500mV 1.8mm 400mA -40C~85C
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.2084
≥1 USD $1.2084
≥10 USD $0.9918
≥100 USD $0.96045
≥500 USD $0.93005
≥1000 USD $0.8987
Inventory: 164002
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Thickness 1.6mm
Width 3.5mm
Length 6.5mm
Height 1.8mm
Technical
Input Voltage Absolute-Max 26V
Dropout Voltage1-Nom 0.5V
Dropout Voltage 500mV
Voltage Dropout (Max) 1V @ 50mA
Current - Quiescent (Iq) 2mA
Protection Features Over Temperature, Reverse Polarity, Short Circuit
Min Input Voltage 4.75V
Number of Regulators 1
Output Voltage 1 3.3V
Accuracy 5 %
Quiescent Current 2mA
Output Configuration Positive
Max Output Current 400mA
Output Type Fixed
Output Voltage 3.3V
Voltage - Input (Max) 26V
Qualification Status Not Qualified
Number of Outputs 1
Current - Supply (Max) 1.25A
Pin Count 3
Base Part Number LM2937
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 2.3mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TR
Subcategory Other Regulators
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 4
Package / Case TO-261-4, TO-261AA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 3 days ago)
