LM2937IMPX-12
RoHS
/
Package TO-261-4, TO-261AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LM2937 Tape & Reel (TR) Surface Mount Over Temperature Reverse Polarity Short Circuit voltage regulator linear 500mV 6.5mm 500mA -40C~85C
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 1584
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.56mm
Length 6.5mm
Technical
Output Voltage Accuracy 5 %
Input Voltage Absolute-Max 26V
Voltage Tolerance-Max 5%
Dropout Voltage1-Nom 0.5V
Dropout Voltage 500mV
Voltage Dropout (Max) 1V @ 50mA
Protection Features Over Temperature, Reverse Polarity, Short Circuit
Number of Regulators 1
Output Voltage 1 12V
Accuracy 5 %
Quiescent Current 2mA
Current - Output 400mA
Output Configuration Positive
Max Output Current 500mA
Output Type Fixed
Output Voltage 12V
Voltage - Input (Max) 26V
Number of Outputs 1
Current - Supply (Max) 20mA
Pin Count 4
Base Part Number LM2937
Terminal Pitch 2.3mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 4
Package / Case TO-261-4, TO-261AA
Mounting Type Surface Mount
Mount Surface Mount
