LM117KRQMLV
RoHS
/
Package TO-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Contains Lead Positive PIN/PEG Not Qualified voltage regulator linear 125C 20W 1.5A 7.75mm
PDF
/
Buying Options
Total Price: USD $572.75
Unit Price: USD $572.75405
≥1 USD $572.75405
Inventory: 35
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Thickness 7.44mm
Width 25.4mm
Length 38.94mm
Height 7.75mm
Technical
Input-Output Voltage Differential-Min 3V
Input-Output Voltage Differential-Max 40V
Line Regulation-Max (%/V) 0.05
Load Regulation-Max(%) 1%
Screening Level MIL-PRF-38535 Class V
Dropout Voltage1-Nom 1.2V
Dropout Voltage 1.5V
Max Input Voltage 41.25V
Min Input Voltage 4.25V
Voltage - Output 37V
Quiescent Current 5mA
Current - Output 1.5A
Power Dissipation-Max 20W
Polarity Positive
Output Type Adjustable
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 2
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Number of Functions 1
Peak Reflow Temperature (Cel) NOT APPLICABLE
Terminal Form PIN/PEG
Terminal Position BOTTOM
Technology BIPOLAR
Subcategory Other Regulators
Min Operating Temperature -55°C
Max Operating Temperature 125°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1
Physical
Number of Pins 2
Surface Mount NO
Package / Case TO-3
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
