LM1117SX-3.3
RoHS
/
Package TO-263
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Positive GULL WING Not Qualified BIPOLAR voltage regulator linear 125C 800mA 4.79mm 1.3V
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 1537
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 8.64mm
Height Seated (Max) 4.79mm
Technical
Line Regulation-Max (%/V) 0.006%
Input Voltage Absolute-Max 20V
Voltage Tolerance-Max 2%
Dropout Voltage1-Nom 1.2V
Dropout Voltage 1.3V
Max Input Voltage 15V
Output Voltage 1 3.3V
Voltage - Output 3.3V
Accuracy 1 %
Quiescent Current 10mA
Current - Output 1.5A
Polarity Positive
Max Output Current 800mA
Output Type Fixed
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position SINGLE
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Other Regulators
Min Operating Temperature 0°C
Max Operating Temperature 125°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 3
Pbfree Code no
JESD-609 Code e0
Physical
Number of Pins 3
Package / Case TO-263
Mount Surface Mount
Alternative Model
