LM1117LD-3.3
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Positive SMD/SMT BIPOLAR e0 voltage regulator linear 125C 800mA 1.3V
PDF
/
Inventory: 7173
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Line Regulation-Max (%/V) 0.006%
Nominal Output Voltage 3.3V
Dropout Voltage1-Nom 1.2V
Dropout Voltage 1.3V
Max Input Voltage 15V
Min Input Voltage 4.5V
Output Voltage 1 3.3V
Voltage - Output 3.3V
Max Output Voltage 3.3V
Accuracy 1 %
Quiescent Current 10mA
Current - Output 800mA
Min Supply Voltage 4.75V
Max Supply Voltage 10V
Voltage 3.3V
Polarity Positive
Max Output Current 800mA
Output Type Fixed
Number of Outputs 1
Terminal Position DUAL
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Other Regulators
Min Operating Temperature 0°C
Max Operating Temperature 125°C
Terminal Finish Tin/Lead (Sn/Pb)
Termination SMD/SMT
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e0
Packaging Cut Tape
Physical
Number of Pins 8
Mount Surface Mount
