TPS61130PWR
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear + Switching
Description
IC REG DL BCK/BST/LINEAR 16TSSOP
PDF
/
Buying Options
Total Price: USD $2.49
Unit Price: USD $2.489
≥1 USD $2.489
≥10 USD $2.0425
≥100 USD $1.97885
≥500 USD $1.91425
≥1000 USD $1.8506
Inventory: 745
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1mm
Width 4.4mm
Length 5mm
Height 1.2mm
Technical
Voltage/Current - Output 2 2.5V~5.5V 320mA
Voltage/Current - Output 1 2.5V~5.5V 300mA
w/Sequencer No
Min Output Voltage 2.5V
Control Technique PULSE WIDTH MODULATION
Max Input Voltage 5.5V
Frequency - Switching 500kHz
Control Mode CURRENT-MODE
Min Input Voltage 1.8V
Topology Step-Down/Step-Up (Buck/Boost) (1), Linear (LDO) (1)
Voltage - Output 2 5.5V
Max Output Voltage 5.5V
Quiescent Current 40μA
Output Current 300mA
Analog IC - Other Type BATTERY CHARGE CONTROLLER
Operating Supply Voltage 6.5V
Voltage - Output 1 5.5V
Max Output Current 1.1A
Output Type Adjustable
Output Voltage 5.5V
Efficiency 90 %
Number of Outputs 2
Pin Count 16
Base Part Number TPS61130
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.8V~5.5V
Subcategory Switching Regulator or Controllers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 62.99264mg
Number of Pins 16
Surface Mount YES
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
Alternative Model
