TPS61103PWR
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear + Switching
Description
IC REG DL BOOST/LNR SYNC 20TSSOP
PDF
/
Buying Options
Total Price: USD $1.8
Unit Price: USD $1.802824
≥1 USD $1.802824
≥10 USD $1.700776
≥100 USD $1.604505
≥500 USD $1.513683
≥1000 USD $1.428007
Inventory: 6934
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Number of Pins 20
Weight 78.187985mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Subcategory Switching Regulator or Controllers
Voltage - Supply 0.8V~3.3V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 0.65mm
Base Part Number TPS61103
Pin Count 20
Number of Outputs 2
Output Voltage 3.6V
Voltage - Output 1 3.3V
Input Voltage-Nom 1.8V
Analog IC - Other Type SWITCHING REGULATOR
Output Current 270mA
Quiescent Current 65μA
Voltage - Output 2 3.6V
Topology Step-Up (Boost) Synchronous (1), Linear (LDO) (1)
Min Input Voltage 800mV
Control Mode CURRENT-MODE
Frequency - Switching 500kHz
Max Input Voltage 3.3V
Control Technique PULSE WIDTH MODULATION
w/Sequencer No
Voltage/Current - Output 1 3.3V 1.8A
Voltage/Current - Output 2 0.9V~3.6V 500mA
Dimensions
Length 6.5mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
