TPS610985DSER
RoHS
RoHS compliant
RoHS compliantPackage 6-WFDFN
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear + Switching
Description
BOOST FIXED 350MA 6WSON
PDF
/
Buying Options
Total Price: USD $1.41
Unit Price: USD $1.408
≥1 USD $1.408
≥10 USD $1.26104
≥100 USD $1.197152
≥500 USD $0.983312
≥1000 USD $0.919142
≥3000 USD $0.812275
Inventory: 8216
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount
Package / Case 6-WFDFN
Surface Mount YES
Number of Pins 6
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Voltage - Supply 0.7V~4.5V
Terminal Position DUAL
Number of Functions 1
Terminal Pitch 0.5mm
Base Part Number TPS610985
Number of Outputs 2
Output Voltage 3V
Input Voltage-Nom 1.5V
Analog IC - Other Type BATTERY CHARGE CONTROLLER
Quiescent Current 300nA
Input Voltage (Min) 0.7V
Topology Step-Up (Boost) Synchronous (1), Linear (LDO) (1)
Control Mode CURRENT-MODE
Input Voltage (Max) 4.5V
Control Technique PULSE WIDTH MODULATION
Switching Frequency-Max 3000kHz
w/Sequencer No
Voltage/Current - Output 1 3V 350mA
Voltage/Current - Output 2 3V 200mA
Dimensions
Height 800μm
Length 1.5mm
Width 1.5mm
Thickness 750μm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
