LM26480QSQX-AA/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 24-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear + Switching
Description
IC REG QUAD BUCK/LNR SYNC 24WQFN
PDF
/
Buying Options
Total Price: USD $4.56
Unit Price: USD $4.56475
≥1 USD $4.56475
≥10 USD $3.7449
≥100 USD $3.62805
≥500 USD $3.5112
≥1000 USD $3.39435
Inventory: 36502
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-WFQFN Exposed Pad
Number of Pins 24
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Switching Regulator or Controllers
Technology CMOS
Voltage - Supply 2.8V~5.5V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Terminal Pitch 0.5mm
Base Part Number LM26480
Pin Count 24
Number of Outputs 4
Efficiency 96 %
Output Voltage 3.3V
Output Type Adjustable
Input Voltage-Nom 3.6V
Analog IC - Other Type SWITCHING REGULATOR
Output Current 1.5A
Quiescent Current 33μA
Topology Step-Down (Buck) Synchronous (2), Linear (LDO) (2)
Min Input Voltage 2.8V
Control Mode VOLTAGE-MODE
Frequency - Switching 2MHz
Control Technique PULSE WIDTH MODULATION
w/Sequencer No
Voltage/Current - Output 1 0.8V~2V 1.5A
Voltage/Current - Output 2 1V~3.3V 1.5A
Voltage/Current - Output 3 1V~3.5V 300mA
Dimensions
Height 800μm
Length 4mm
Width 4mm
Thickness 750μm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
