TC1313-ZS0EUNTR
RoHS
RoHS compliant
RoHS compliantPackage 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear + Switching
Description
IC REG DL BCK/LINEAR SYNC 10MSOP
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.388214
≥1 USD $1.388214
≥10 USD $1.309632
≥100 USD $1.235507
≥500 USD $1.165575
≥1000 USD $1.099599
Inventory: 1539
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 3mm
Height 850μm
Technical
Voltage/Current - Output 2 1.5V 300mA
Voltage/Current - Output 1 Adj 500mA
w/Sequencer No
Current - Output 1 500mA
Supply Current-Max (Isup) 0.1mA
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 5.5V
Frequency - Switching 2MHz
Control Mode CURRENT-MODE
Topology Step-Down (Buck) Synchronous (1), Linear (LDO) (1)
Voltage - Output 2 1.5V
Output Current 500mA
Analog IC - Other Type SWITCHING REGULATOR
Power Supplies 3/5V
Input Voltage-Nom 3.6V
Output Voltage 800mV
Number of Outputs 2
Pin Count 10
Base Part Number TC1313
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Subcategory Power Management Circuits
Additional Feature PFM CONTROL TECHNIQUE ALSO POSSIBLE; OUTPUT VOLTAGE IS ADJUSTABLE UPTO 0.8 TO 4.5
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 10
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
