TC1303B-AG0EUN
RoHS
/
Package 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear + Switching
Description
IC REG DL BCK/LINEAR SYNC 10MSOP
PDF
/
Inventory: 5616
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Number of Pins 10
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2005
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature AUTOMATIC PWM TO PFM MODE
Subcategory Power Management Circuits
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.5mm
Frequency 2MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number TC1303B
Pin Count 10
Number of Outputs 2
Voltage - Output 1 3.3V
Input Voltage-Nom 3.6V
Power Supplies 3/5V
Analog IC - Other Type SWITCHING REGULATOR
Output Current 500mA
Voltage - Output 2 2.7V
Topology Step-Down (Buck) Synchronous (1), Linear (LDO) (1)
Control Mode CURRENT-MODE
Input Voltage (Max) 5.5V
Control Technique PULSE WIDTH MODULATION
Supply Current-Max (Isup) 0.11mA
w/Sequencer Yes
Voltage/Current - Output 1 3.3V 500mA
Voltage/Current - Output 2 2.7V 300mA
w/LED Driver No
Dimensions
Height 850μm
Length 3mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
