XRP7725ILB-F
RoHS
RoHS compliant
RoHS compliantPackage 44-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear + Switching
Description
IC REG 6OUT BUCK/LINEAR 44TQFN
PDF
/
Buying Options
Total Price: USD $141.01
Unit Price: USD $141.0085
≥1 USD $141.0085
≥10 USD $136.30885
≥100 USD $122.208
Inventory: 707
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 0.8mm
Technical
w/Supervisor No
Voltage/Current - Output 3 Controller
w/Sequencer Yes
Frequency - Switching 105kHz~1.23MHz
Topology Step-Down (Buck) (4), Linear (LDO) (2)
Adjustable Threshold YES
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 6
Supply Voltage-Min (Vsup) 5.5V
Supply Voltage-Max (Vsup) 25V
Number of Outputs 6
JESD-30 Code S-XQCC-N44
Terminal Pitch 0.5mm
Supply Voltage 12V
Number of Functions 1
Terminal Position QUAD
Voltage - Supply 4.75V~25V
HTS Code 8542.39.00.01
Additional Feature OTHER SUPPLY VOLTAGE IS 4.75 V TO 5.5 V
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Published 2014
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 44-WFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
