MAX1765EEE
RoHS
/
Package 16-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear + Switching
Description
IC REG DL BOOST/LNR SYNC 16QSOP
PDF
/
Buying Options
Total Price: USD $5.31
Unit Price: USD $5.309727
≥1 USD $5.309727
≥10 USD $5.009181
≥100 USD $4.725636
≥500 USD $4.458147
≥1000 USD $4.205798
Inventory: 1274
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 3.9mm
Length 4.89mm
Height Seated (Max) 1.73mm
Technical
Voltage/Current - Output 2 2.85V/Adj 500mA
Voltage/Current - Output 1 2.5V~5.5V 800mA
w/Sequencer No
Control Technique PULSE WIDTH MODULATION
Max Input Voltage 5.5V
Frequency - Switching 1MHz
Control Mode VOLTAGE-MODE
Min Input Voltage 700mV
Topology Step-Up (Boost) Synchronous (1), Linear (LDO) (1)
Voltage - Output 2 2.85V
Output Power 667mW
Output Current 800mA
Analog IC - Other Type SWITCHING REGULATOR
Operating Supply Voltage 5.5V
Voltage - Output 1 5.5V
Max Output Current 800mA
Output Voltage 5.5V
Efficiency 93 %
Number of Outputs 2
Pin Count 16
Base Part Number MAX1765
Time@Peak Reflow Temperature-Max (s) 20
Terminal Pitch 0.635mm
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 0.7V~5.5V
Subcategory Switching Regulator or Controllers
Terminal Finish Tin/Lead (Sn85Pb15)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2011
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 16
Package / Case 16-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
