LTC1704EGN#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear + Switching
Description
IC REG DL BUCK/LNR 550KHZ 16SSOP
PDF
/
Inventory: 8850
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-SSOP (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2003
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Technology BICMOS
Voltage - Supply 3.15V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.635mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LTC1704
Pin Count 16
JESD-30 Code R-PDSO-G16
Number of Outputs 2
Input Voltage-Nom 5V
Input Voltage (Min) 3.15V
Topology Step-Down (Buck) (1), Linear (LDO) (1)
Control Mode VOLTAGE-MODE
Output Current-Max 5A
Frequency - Switching 550kHz
Input Voltage (Max) 5.5V
Control Technique PULSE WIDTH MODULATION
Switcher Configuration PUSH-PULL
w/Sequencer No
Voltage/Current - Output 1 Controller
Dimensions
Length 4.8895mm
Width 3.899mm
Compliance
RoHS Status ROHS3 Compliant
