ST715PUR
RoHS
RoHS compliant
RoHS compliantPackage 8-VDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
ST715 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 1V 3mm 85mA 5W
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8272
≥1 USD $0.8272
≥10 USD $0.72688
≥100 USD $0.682528
≥500 USD $0.556952
≥1000 USD $0.51737
≥3000 USD $0.440317
Inventory: 1338
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-VDFN Exposed Pad
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Packing Method TAPE AND REEL
Max Power Dissipation 5W
Technology BIPOLAR
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Base Part Number ST715
Pin Count 8
Current - Supply (Max) 6.5μA
Number of Outputs 1
Voltage - Input (Max) 24V
Output Voltage 23.5V
Output Type Adjustable
Max Output Current 85mA
Output Configuration Positive
Power Dissipation 5W
Quiescent Current 5.5μA
Number of Regulators 1
Min Input Voltage 2.5V
Protection Features Over Current, Over Temperature
Voltage Dropout (Max) 1V @ 85mA
PSRR 62dB ~ 45dB (100kHz ~ 1kHz)
Dropout Voltage 1V
Dropout Voltage1-Nom 0.5V
Min Output Voltage 1.2V
Power Supply Rejection Ratio (PSRR) 62dB
Voltage - Output (Max) 23V
Dimensions
Length 3mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
