ST2L05R3300PS
RoHS
RoHS compliant
RoHS compliantPackage 8-VDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
FIXED/ADJUSTABLE ST2L05 Tape & Reel (TR) Surface Mount voltage regulator linear 1.1V 6mm 1A 1A 0C~125C
PDF
/
Buying Options
Total Price: USD $1.96
Unit Price: USD $1.9624
≥1 USD $1.9624
≥10 USD $1.76528
≥100 USD $1.665312
≥500 USD $1.418912
≥1000 USD $1.33232
≥3000 USD $1.165771
Inventory: 4776
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5mm
Length 6mm
Height Seated (Max) 1mm
Technical
Load Regulation-Max(%) 0.4%
Adjustability FIXED/ADJUSTABLE
Output Voltage Accuracy 2 %
Input Voltage Absolute-Max 10V
Min Current Limit 1A
Voltage Tolerance-Max 3%
Dropout Voltage1-Nom 1.3V
Dropout Voltage 1.1V
Reference Voltage 1.275V
PSRR 60dB (120Hz)
Voltage Dropout (Max) 1.3V @ 1A 1.3V @ 1A
Protection Features Over Current, Over Temperature
Min Input Voltage 4.5V
Number of Regulators 2
Voltage - Output (Min/Fixed) 1.25V 3.3V
Output Voltage 1 3.3V
Accuracy 2 %
Quiescent Current 5mA
Current - Output 1A 1A
Output Configuration Positive
Output Type Adjustable (Fixed)
Output Voltage 5.7V
Voltage - Input (Max) 7V
Number of Outputs 2
Pin Count 8
Base Part Number ST2L05
Time@Peak Reflow Temperature-Max (s) 30
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 0°C~125°C
Physical
Number of Pins 8
Package / Case 8-VDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
