LM723N
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LM723 Tube Through Hole Over Current voltage regulator linear 9.5V 2.54mm 150mA -55C~125C
PDF
/
Buying Options
Total Price: USD $2.27
Unit Price: USD $2.271517
≥1 USD $2.271517
≥10 USD $2.142934
≥100 USD $2.021629
≥500 USD $1.907199
≥1000 USD $1.799251
Inventory: 1537
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Technical
Load Regulation-Max(%) 0.6%
PSRR 86db ~ 74dB (100Hz ~ 10kHz)
Current - Quiescent (Iq) 5mA
Protection Features Over Current
Min Input Voltage 9.5V
Number of Regulators 1
Voltage - Output (Min/Fixed) 2V
Current - Output 150mA
Output Configuration Positive
Output Type Adjustable
Output Voltage 37V
Voltage - Input (Max) 40V
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 14
Base Part Number LM723
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology BIPOLAR
Subcategory Other Regulators
Terminal Finish NICKEL PALLADIUM GOLD
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
