LM723CD013TR

STMicroelectronics
RoHS
RoHS RoHS compliant
Package 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description LM723 Tape & Reel (TR) Surface Mount Over Current voltage regulator linear 9.5V 8.65mm 150mA 0C~70C
PDF
/
Inventory: 8172
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14

Technical

Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Terminal Finish Tin (Sn)
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LM723
Pin Count 14
Qualification Status Not Qualified
Voltage - Input (Max) 40V
Output Voltage 37V
Output Type Adjustable
Output Configuration Positive
Current - Output 150mA
Voltage - Output (Min/Fixed) 2V
Number of Regulators 1
Min Input Voltage 9.5V
Protection Features Over Current
Current - Quiescent (Iq) 4mA
PSRR 86db ~ 74dB (100Hz ~ 10kHz)

Dimensions

Length 8.65mm
Width 3.9mm

Compliance

RoHS Status ROHS3 Compliant
