LM317D2T-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LM317 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 37V 4.57mm 1.5A 0C~125C
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4344
≥1 USD $1.4344
≥10 USD $1.28216
≥100 USD $1.216864
≥500 USD $0.999592
≥1000 USD $0.934454
≥3000 USD $0.825792
Inventory: 43654
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Weight 2.012816mg
Technical
Operating Temperature 0°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Subcategory Other Regulators
Packing Method TR
Technology BIPOLAR
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LM317
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Outputs 1
Voltage - Input (Max) 40V
Output Voltage 37V
Output Type Adjustable
Max Output Current 1.5A
Output Configuration Positive
Max Output Voltage 37V
Number of Regulators 1
Min Input Voltage 3V
Protection Features Over Current, Over Temperature
PSRR 80dB ~ 65dB (120Hz)
Reference Voltage 1.3V
Min Output Voltage 1.2V
Power Supply Rejection Ratio (PSRR) 80dB
Voltage - Output (Max) 37V
Dimensions
Height 4.57mm
Length 10.24mm
Width 9.35mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
