LF80ABV
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LF80 Tube Through Hole Over Current Over Temperature voltage regulator linear 400mV 2.54mm 500mA -40C~125C
PDF
/
Inventory: 5212
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Input Bias Current 700μA
Input Voltage Absolute-Max 40V
Voltage Tolerance-Max 2%
Dropout Voltage1-Nom 0.4V
Dropout Voltage 400mV
PSRR 72dB ~ 57dB (120Hz ~ 10kHz)
Voltage Dropout (Max) 0.7V @ 500mA
Current - Quiescent (Iq) 1.5mA
Protection Features Over Current, Over Temperature
Number of Regulators 1
Input Voltage (Min) 9V
Output Voltage 1 8V
Current - Output 500mA
Output Configuration Positive
Output Type Fixed
Output Voltage 8V
Voltage - Input (Max) 16V
Qualification Status Not Qualified
Number of Outputs 1
Current - Supply (Max) 12mA
JESD-30 Code R-XSFM-T3
Pin Count 3
Base Part Number LF80
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology BIPOLAR
Subcategory Other Regulators
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
