LF50ACP
RoHS
/
Package TO-220-3 Full Pack
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TO-220-3Full Pack Through Hole Over Current Over Temperature Non-RoHS Compliant voltage regulator linear 0.4V 20mm 500mA -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 992
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Surface Mount NO
Technical
Operating Temperature -40°C~125°C TJ
JESD-609 Code e0
Part Status Active
Number of Terminations 3
Terminal Finish Tin/Lead (Sn/Pb)
Technology BIPOLAR
Terminal Position SINGLE
Number of Functions 1
Terminal Pitch 2.55mm
Reach Compliance Code not_compliant
JESD-30 Code R-PSFM-T3
Current - Supply (Max) 12mA
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) 16V
Output Type Fixed
Output Configuration Positive
Current - Output 500mA
Output Voltage 1 5V
Input Voltage (Min) 6V
Voltage - Output (Min/Fixed) 5V
Number of Regulators 1
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 1mA
Voltage Dropout (Max) 0.7V @ 500mA
PSRR 76dB ~ 60dB (120Hz ~ 10kHz)
Dropout Voltage1-Nom 0.4V
Output Voltage1-Min 4.875V
Input Voltage Absolute-Max 40V
Dimensions
Height Seated (Max) 20mm
Width 4.5mm
Compliance
RoHS Status Non-RoHS Compliant
