LF120CPT
RoHS
RoHS compliant
RoHS compliantPackage TO-252-5, DPak (4 Leads + Tab), TO-252AD
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LF120 Tube Surface Mount Over Current Over Temperature voltage regulator linear 400mV 2.63mm 500mA -40C~125C
PDF
/
Buying Options
Total Price: USD $1.68
Unit Price: USD $1.682079
≥1 USD $1.682079
≥10 USD $1.586866
≥100 USD $1.497048
≥500 USD $1.412311
≥1000 USD $1.33236
Inventory: 1150
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 2.63mm
Technical
Output Voltage Accuracy 2 %
Input Bias Current 700μA
Input Voltage Absolute-Max 40V
Voltage Tolerance-Max 4%
Dropout Voltage1-Nom 0.4V
Dropout Voltage 400mV
PSRR 69dB ~ 54dB (120Hz ~ 10kHz)
Voltage Dropout (Max) 0.7V @ 500mA
Protection Features Over Current, Over Temperature
Number of Regulators 1
Output Voltage 1 12V
Control Features Enable
Quiescent Current 1.5mA
Current - Output 500mA
Output Configuration Positive
Output Type Fixed
Output Voltage 12V
Voltage - Input (Max) 16V
Qualification Status Not Qualified
Number of Outputs 1
Current - Supply (Max) 12mA
JESD-30 Code R-XSFM-T3
Pin Count 3
Base Part Number LF120
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form THROUGH-HOLE
Terminal Position SINGLE
Technology BIPOLAR
Subcategory Other Regulators
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Package / Case TO-252-5, DPak (4 Leads + Tab), TO-252AD
Mounting Type Surface Mount
Mount Surface Mount
