LDR1833K7-R
RoHS
RoHS compliant
RoHS compliantPackage SPak-7 (7 leads + Tab)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LDR1833 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 400mV 9.395mm 500mA 1A -40C~125C
PDF
/
Inventory: 9163
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 8mm
Length 9.395mm
Technical
Output Voltage 2 3.3V
Input Bias Current 30mA
Input Voltage Absolute-Max 15V
Voltage Tolerance-Max 5%
Dropout Voltage1-Nom 0.4V
Dropout Voltage 400mV
PSRR 70dB (120Hz)
Voltage Dropout (Max) 0.8V @ 1A
Current - Quiescent (Iq) 50μA
Protection Features Over Current, Over Temperature, Short Circuit
Min Input Voltage -300mV
Number of Regulators 2
Voltage - Output (Min/Fixed) 1.8V 3.3V
Output Voltage 1 1.8V
Accuracy 5 %
Control Features Enable
Current - Output 500mA 1A
Output Configuration Positive
Output Type Fixed
Output Voltage 3.3V
Voltage - Input (Max) 15V
Number of Outputs 2
Current - Supply (Max) 1.6mA
Pin Count 7
Base Part Number LDR1833
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish TIN LEAD
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 7
Package / Case SPak-7 (7 leads + Tab)
Mounting Type Surface Mount
Mount Surface Mount
