LDK220M32R
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LDK220 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 3.296V 2.95mm 200mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.8008
≥1 USD $0.8008
≥10 USD $0.7084
≥100 USD $0.66528
≥500 USD $0.542784
≥1000 USD $0.504205
≥3000 USD $0.429106
Inventory: 3044
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 2.95mm
Technical
Output Voltage1-Max 3.296V
PSRR 55dB ~ 50dB (120Hz ~ 10kHz)
Voltage Dropout (Max) 0.35V @ 200mA
Current - Quiescent (Iq) 90μA
Protection Features Over Current, Over Temperature
Number of Regulators 1
Voltage - Output (Min/Fixed) 3.2V
Input Voltage (Min) 4.2V
Output Voltage 1 3.2V
Control Features Enable
Current - Output 200mA
Output Configuration Positive
Output Type Fixed
Voltage - Input (Max) 13.2V
Current - Supply (Max) 100μA
JESD-30 Code R-PDSO-G5
Base Part Number LDK220
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.95mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 14 Weeks
