LDK120PU10R
RoHS
RoHS compliant
RoHS compliantPackage 6-XFDFN
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LDK120 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 300mV 450mum 200mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.7216
≥1 USD $0.7216
≥10 USD $0.63712
≥100 USD $0.598752
≥500 USD $0.488664
≥1000 USD $0.453869
≥3000 USD $0.386267
Inventory: 744
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 1.2mm
Length 1.3mm
Height 450μm
Technical
Nominal Output Voltage 1V
Voltage Tolerance-Max 3%
Power Supply Rejection Ratio (PSRR) 55dB
Dropout Voltage1-Nom 1V
Dropout Voltage 300mV
PSRR 55dB (120Hz ~ 10kHz)
Voltage Dropout (Max) 0.3V @ 200mA
Protection Features Over Current, Over Temperature
Min Input Voltage 1.9V
Number of Regulators 1
Output Voltage 1 1V
Accuracy 2 %
Control Features Enable
Quiescent Current 60μA
Output Configuration Positive
Operating Supply Current 50μA
Max Output Current 200mA
Output Type Fixed
Output Voltage 1V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Current - Supply (Max) 100μA
Base Part Number LDK120
Terminal Pitch 0.4mm
Number of Functions 1
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Other Regulators
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 6
Package / Case 6-XFDFN
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 12 Weeks
