LD3985J28R
RoHS
RoHS compliant
RoHS compliantPackage 5-WFBGA, FCBGA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LD3985 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 60mV 150mA -40C~125C
PDF
/
Inventory: 4546
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Input Bias Current 85μA
Input Voltage Absolute-Max 6V
Min Current Limit 300mA
Voltage Tolerance-Max 3%
Dropout Voltage1-Nom 0.06V
Dropout Voltage 60mV
PSRR 60dB ~ 50dB (1kHz ~ 10kHz)
Voltage Dropout (Max) 0.1V @ 150mA
Current - Quiescent (Iq) 150μA
Protection Features Over Current, Over Temperature
Min Input Voltage 2.5V
Number of Regulators 1
Output Voltage 1 2.8V
Accuracy 2 %
Control Features Enable
Quiescent Current 150μA
Current - Output 150mA
Output Configuration Positive
Output Type Fixed
Output Voltage 2.8V
Voltage - Input (Max) 6V
Number of Outputs 1
Current - Supply (Max) 250μA
Pin Count 5
Base Part Number LD3985
Time@Peak Reflow Temperature-Max (s) 30
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology BICMOS
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish TIN SILVER COPPER
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
JESD-609 Code e1
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Package / Case 5-WFBGA, FCBGA
Mounting Type Surface Mount
Mount Surface Mount
