LD39115J18R
RoHS
RoHS compliant
RoHS compliantPackage 4-UFBGA, FCBGA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LD39115 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 80mV 0.788mm 150mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.9
Unit Price: USD $0.8976
≥1 USD $0.8976
≥10 USD $0.80168
≥100 USD $0.760672
≥500 USD $0.624712
≥1000 USD $0.583968
≥3000 USD $0.516067
Inventory: 1217
Minimum: 1
-
+
Technical Details
Technical
Packing Method TAPE AND REEL
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Number of Functions 1
Base Part Number LD39115
Pin Count 4
Current - Supply (Max) 70μA
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Voltage 1.8V
Output Type Fixed
Max Output Current 150mA
Output Configuration Positive
Quiescent Current 50μA
Control Features Enable
Accuracy 2 %
Output Voltage 1 1.8V
Number of Regulators 1
Min Input Voltage 1.5V
Protection Features Over Current, Over Temperature
Voltage Dropout (Max) 0.11V @ 100mA
PSRR 74dB ~ 67dB (1kHz ~ 10kHz)
Dropout Voltage 80mV
Dropout Voltage1-Nom 0.08V
Voltage Tolerance-Max 3%
Input Voltage Absolute-Max 6V
Output Voltage Accuracy 2 %
Subcategory Other Regulators
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Dimensions
Height Seated (Max) 0.6mm
Length 0.788mm
Width 0.788mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 4
Package / Case 4-UFBGA, FCBGA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 24 Weeks
